Dimension

Complete Set

  2219*919*120mm

Main Screen

Touch Panel Size

55″ |  65″ LED Panel

Resolution

3840(H)×2160(V) (UHD)

Color

1.07B (8-bit+Dithering)

Brightness

350cd/m2

Contrast

4000:1 (according to panel brand)

Viewing Angle

178°

Electrical performance

Max Power

≤160W

Standby Power

≤0.5W

Voltage

110-240V(AC) 50/60Hz

Operating System

(Dual OS available)

Android System

Android 11.0,

CPU: A53*4,Quad core,1.5GHZ ;  GPU: Mali G52

Storage: RAM 2/4GB ,ROM 32G;  Network: LAN/WiFi; Bluetooth included

OPS/Windows System

CPU: I3/i5/ i7;

Storage: 4/8/16G; 128G/256/512 SSD or 1T HDD;

Windows: Pre-install Win 10/11 Pro

Touch

Touch Technology

IR touch; 20 points; HIB Free drive

Touch Items

Main screen and sub-screen can work simultaneously.

Response Speed

≤ 8ms

Operation System

Support Windows7/10, Android, Mac OS, Linux

Speakers

Power

10W*2 / 8Ω

Ports of main screen

Rear Ports

HDMI*1,VGA*1,AUDIO*1; Earphone*1,USB2.0*2,Touch USB*1,RF*1, OPS slot*1

Front Ports

USB2.0*2

Camera Pixel

8M pixels

Lens

Fixed focal length lens, effective focal length 4.11mm

Perspective

Horizontal viewing angle 68.6 degrees, focus 76.1 degrees

Main camera focus

 Fixed focus lens, effective focal length 4.11mm

Max no. of frames

30

Drive

Free drive

Video resolution

1920*1080, 3840*2160

Microphone type

Digital array microphone

No. of digital marks

8 pcs

Sensitivity

-38db

Noise ratio signal

63db

Pickup distance

5~8 m

Drive

Win10 free drive

Accessories List

Power cable*1 pcs; Remote Controller*1 pcs; Touch Pen*1 pcs; Marker *1pcs,Instruction manual*1 pcs ;

Warranty card*1 pcs; Wall brackets*1 set;
